292
Front View Monitor
& How to access the Front View Monitor
S06BA01
1 Front view monitor switch
To change over to the camera screen , perform either of the following operations when the ignition switch is in the “ ACC ” or “ ON ” position .
. Press the front view monitor switch . . Shift the select lever from “ R ” to “ D ”.
& How to cancel the Front View Monitor
S06BA02
! Manual cancellation
S06BA0201
. Press the front view monitor switch . . Press the INFO button .
! Automatic cancellation
S06BA0202
If any of the following conditions are met , the Front View Monitor is canceled automatically .
After accessing the Front View Monitor by pressing the front view monitor switch :
. Approximately 3 minutes have passed since the last operation .
. The vehicle speed becomes 13 mph ( 20 km / h ) or more *.
. The select lever is shifted to the “ P ” position .
. The parking brake is applied .
*: The Front View Monitor can be activated when pressing the front view monitor switch , regardless of the vehicle speed .
*: When the Front View Monitor is activated at speeds of more than 13 mph ( 20 km / h ), to cancel the Front View Monitor , the vehicle speed needs to be decreased to less than 13 mph ( 20 km / h ) and then increased to more than 13 mph ( 20 km / h ).
After accessing the Front View Monitor using the select lever :
. Shift the select lever into the “ P ” position .
. The vehicle speed becomes 5 mph ( 8 km / h ) or more .
. Approximately 9 seconds have passed since the last operation .
. The parking brake is applied .
& How to adjust the display contrast and brightness
S06BA06
The contrast and brightness of the front view monitor display can be adjusted . For details , refer to “ Camera settings ” FP222 .
