Cargo area cover 287
6-12 . Cargo area cover ( if equipped )
S06AK
The cargo area cover is provided for covering the cargo area and to protect its contents from direct sunlight . This cover is detachable to make room for additional cargo .
& Using the cover
S06AK01
WARNING
Do not place anything on the extended cover . Putting excessive weight on the extended cover can break it and an object on the cover could tumble forward in the event of a sudden stop or collision . This could cause serious injury .
CAUTION
Be careful not to scratch the rear gate stays while extending and rewinding the cover . Scratches on the stays could cause leakage of gas from the stays , which may result in their inability to hold the rear gate open .
& To install the front part of the cover
S06AK08
CAUTION
For models with a reclining rear seatback , when reclining , move the front part of the cover back so that it is not damaged .
Interior equipment
To extend the cover , pull the end of the cover out of the housing , then insert its hooks into the catches as shown . To rewind it , unhook it from the catches and it will rewind automatically . You should hold on to the cover and guide it back into the cover housing while it is rewinding .
1 . Align the right side of the front cover with the triangle mark before fixing the cover in place .
2 . Align the left side of the front cover with the triangle mark before fixing the cover in place .
3 . Push the front cover to the right side and adjust the size of the bar as necessary .
– CONTINUED –
