Multi-function display ( color LCD ) 215 |
||||||
|
! Register User
S03BP281002
1 . Adjust the seat position , outside mirror angle , and reverse tilt-down outside mirror angle so that you are seated in the correct driving posture .
NOTE
. Start the user registration after adjusting the seat position , outside mirror angle , and reverse tilt-down outside mirror angle . If they are adjusted during user registration , it may be disrupted . Refer to “ Power seat ” FP34 or “ Outside mirrors ” FP249 .
. If the ignition switch is turned to the “ OFF ” position before user registration is complete , the information of the adjusted seat position , outside mirror angle , and reverse tilt-down outside mirror angle will not be saved .
2 . Select “ Register User ” from the 2nd menu in the settings screen . Refer to “ Setting screen ” FP211 .
|
||||||
|
2 . Select “ Yes ” to start the repeat facial scan . Select “ No ” to return to the previous screen .
3 . While seated in the driver ’ s seat , face straight forward and wait for a few moments .
|
When user recognition is completed , the Hello screen appears and the screen then switches to the basic screen associated with the user information . |
Instruments and controls |
||||
– CONTINUED – |
