Multi-function display ( color LCD ) 211 |
||||||||||
|
! Guidance screen
S03BP101910
|
When the INFO button on the steering wheel is pressed and held on this screen , the setting screen can be displayed .
For details , refer to “ Setting screen ” FP211 .
|
NOTE
When the combination meter display ( color LCD ) is displaying the menu screen entering screen , the system will not move to the setting screen even if the INFO button is pressed and held .
|
& Setting screen
S03BP28
1 . Press and hold the INFO button on the guidance screen . The top menu is displayed .
2 . Operate the “ ” or “ ” switch to select the preferred menu from the top menu .
3 . Pull the “ / SET ” switch to enter the selected menu .
4 . Operate the “ ” or “ ” switch to select the preferred menu from the 2nd menu .
5 . Pull the “ / SET ” switch to enter the selected menu .
|
Instruments and controls |
||||||
– CONTINUED – |
