162
Hazard warning flasher
! Battery drainage prevention function
S03BG0201
The push-button ignition switch automatically switches to the “ OFF ” position to prevent the battery from going dead under either of the following conditions :
. The push-button ignition switch is left in the “ ACC ” position for about 20 minutes when the select lever is in the “ P ” position .
. The push-button ignition switch is left in the “ ON ” position for about 1 hour when the select lever is in the “ P ” position .
& When access key fob does not operate properly
S03BG03
Refer to “ Access key fob – if access key fob does not operate properly ” FP433 .
3-3 . Hazard warning flasher
S03AB
The hazard warning flasher is used to warn other drivers when you have to park your vehicle under emergency conditions . The hazard warning flasher works regardless of the position of the ignition switch .
To turn on the hazard warning flasher , push the hazard warning flasher switch on the instrument panel . All the turn signal lights and the turn signal indicator lights will flash . To turn off the flasher , push the switch again .
NOTE
When the hazard warning flasher is on , the turn signals do not work .
3-4 . Meters and gauges
S03AD
NOTE
Some of the meters and gauges on the combination meter use liquid-crystal displays . You will find their indications hard to see if you wear polarized glasses .
& Speedometer
S03AD03
The speedometer shows the vehicle speed .
& Tachometer
S03AD06
The tachometer shows the engine speed in thousands of revolutions per minute .
CAUTION
Do not operate the engine with the pointer of the tachometer in the red zone . In this range , fuel injection will be cut by the engine control module to protect the engine from overrevving . The engine will resume running normally after the engine speed is reduced below the red zone .
