Child restraint systems
. Upper anchorages (tether anchorages)
C: Rear seat, center seating position
In this position, the following equipment is
provided for installing a child restraint
system.
. ALR/ELR seatbelts
. Lower anchorages (bars)
. Top tether anchorages
Some types of child restraints might not be
able to be secured firmly due to projection
of the seat cushion.
In this seating position, you should use
only a child restraint system that has a
bottom base that fits snugly against the
contours of the seat cushion and can be
securely retained using the seatbelt.
The rear center seat includes lower an-
chorages, and the lower anchorages on
the center side of the rear right seat can be
used to install a child restraint system.
When a child restraint system is installed in
WARNING
. Even with advanced airbags, chil-
dren can be seriously injured by
the airbag. Place children in the
rear seat properly restrained at
all times. The SRS airbag deploys
with considerable speed and
force and can injure or even kill
children, especially if they are not
restrained or improperly re-
strained. Because children are
lighter and weaker than adults,
their risk of being injured from
deployment is greater.
For that reason, be sure to secure
ALL types of child restraint de-
vices (including forward facing
child seats) in the REAR seats at
all times. You should choose a
restraint device which is appro-
priate for the child’s age, height
and weight. According to acci-
dent statistics, children are safer
when properly restrained in the
rear seating positions than in the
front seating positions.
. Do not use lower anchorages
(bars) for a seat in the center
seating position unless a child
restraint system manufacturer’s
instructions permit and specify
using anchors spaced as far
apart as those in this vehicle.
. Do not connect two or more lower
hooks onto the same anchorage
(bar).
– CONTINUED –
Some types of child restraints might not be
able to be secured firmly due to projection
of the seat cushion.
In this seating position, you should use
only a child restraint system that has a
bottom base that fits snugly against the
contours of the seat cushion and can be
securely retained using the seatbelt.
the rear center seat using the lower
anchorages, do not sit in the rear right
seat.
If a child restraint system is not correctly
fixed in place (for example, if a child
restraint system can be moved more than
1 inch (2.5 cm) from side to side), the child
restraint system should be moved to a
window seat position of the rear seat.
63
