58
Seatbelt pretensioners
surrounding area has been damaged,
contact your SUBARU dealer as soon
as possible.
. When you sell your vehicle, we urge
you to inform the buyer that the vehicle
is equipped with seatbelt preten-
sioners. Also, notify the buyer of the
contents in this section.
& Seatbelt with shoulder belt
pretensioner
S01AF01
NOTE
This section is applicable to the follow-
ing components.
. Rear passenger’s seatbelt (window-
side)
. SRS frontal airbag sensor
. Side impact sensor
. Rollover sensor & Seatbelt with shoulder belt
and lap belt pretensioners
S01AF02
NOTE
If the sensor detects a certain predeter-
mined amount of force during frontal or
side collisions or rollover accidents, any
seatbelt that has a seatbelt pretensioner is
quickly drawn back in by the retractor to
take up the slack so that the belt more
effectively restrains the seat occupant. This section is applicable to the front
seatbelt.
The rear passenger’s seatbelt (window-
side) pretensioner includes a tension
reducing device which limits the peak
forces exerted by the seatbelt on the
occupant in the event of a collision.
When a seatbelt pretensioner is activated,
an operating noise will be heard and a
small amount of smoke will be released.
These occurrences are normal and not
harmful. This smoke does not indicate a
fire in the vehicle.
Once the seatbelt pretensioner has been
activated, the seatbelt retractor remains
locked. Consequently, the seatbelt can not
be pulled out and retracted and therefore
must be replaced.
The pretensioner sensor also serves as
follows.
1)
2)
Seatbelt retractor assembly (shoulder
belt pretensioner and adaptive force
limiter)
Lap belt pretensioner
The shoulder belt pretensioner is supple-
mented by a lap belt pretensioner, which is
located at the base of the center pillar. Like
the shoulder belt pretensioner, the lap belt
pretensioner instantaneously pulls in the
belt to eliminate slack if a certain level of
frontal collision force is detected. As a
result, the seatbelt restrains the front seat
occupant more effectively.
