Seat heater
1-4. Seat heater (if equipped)
The seat heater operates when the ignition
switch is either in the “ACC” or “ON”
position.
& Safety precautions
S01AB03
CAUTION
. People with delicate skin may
suffer slight burns even at low
temperatures if they use the seat
heater for a long period of time.
When using the heater, always be
sure to warn the persons con-
cerned.
. Do not put anything on the seat
which insulates against heat,
such as a blanket, cushion, or
similar items. This may cause the
seat heater to overheat.
. When the seat is warmed enough
or before you leave the vehicle,
be sure to turn off the seat heater.
Use of the seat heater for a long period
of time while the engine is not running
can cause battery discharge.
& Front seat heater
S01AB05
Front seats
1) HI – Rapid heating
2) LO – Normal heating
3) Off
A) Left-hand side
B) Right-hand side
To turn on the seat heater, push the “LO” or
“HI” position on the switch, as desired,
depending on the temperature.
Selecting the “HI” position will cause the
seat to heat up quicker.
To turn off the seat heater, lightly press the
opposite side of the current position.
The indicator located on the switch illumi-
nates when the seat heater is in operation.
& Rear seat heater (if equipped)
S01AB06
CAUTION
Do not open and close the center
console lid while operating the rear
seat heater switch. There is the risk
of fingers being caught in the lid.
The seat heater operates when the ignition
switch is in the “ON” position.
– CONTINUED –
S01AB
The seat heater is equipped in the front
seats or rear seats (window side seating
position).
NOTE
47
