Multi-function display (color LCD)
! Favorite setting
221
! Beep setting
! Bypass screen setting
S03BP280503 S03BP280504
1. Select “Bypass Screen” from the 2nd
menu in the setting screen. Refer to
“Setting screen” FP212. 1. Select “Beep” from the 2nd menu in the
setting screen. Refer to “Setting screen”
FP212.
2. Set the desired items by using the
control switches. For details about items,
refer to “Favorite screen” FP209.
3. Select “Set” to exit settings. Select “Go
Back” to return to the previous screen
without applying the setting changes. 2. Select “On” or “Off” to turn the display
of items on or off by using the control
switches.
3. Select “Set” to exit settings. Select “Go
Back” to return to the previous screen
without applying the setting changes. 2. Set the beep volume by using the
control switches.
3. Select “Set” to exit settings. Select “Go
Back” to return to the previous screen
without applying the setting changes.
S03BP280502 1. Select the “Favorite” from the 2nd
menu in setting screen. Refer to “Setting
screen” FP212.
NOTE
. You can display a maximum of the 3
items.
. The same item cannot be selected
for the left, center or right location.
. Weather information for 3 hours
later or 6 hours later can be displayed.
NOTE
Traffic information setting is only dis-
played for the audio unit with SiriusXM
satellite radio.
– CONTINUED –
