190
5)
6)
7)
8)
9)
A:
B:
Combination meter display (color LCD)
Telltale screen (refer to “Telltale screen”
FP191.)
Select lever/gear position indicator (refer
to “Select lever/gear position indicator”
FP184.)
X-MODE indicator (if equipped) (refer to
“X-MODE indicator light” FP187.) SI-
DRIVE indicator (refer to “SI-DRIVE
indicator light” FP184.)
Odometer (refer to “Odometer” FP161.)/
double trip meter (refer to “Double trip
meter” FP161.)
Fuel gauge (refer to “Fuel gauge”
FP162.)
Deactivating the Eyesight system or
models without EyeSight system
Activating the Eyesight system
& Basic operation
S03BN01
original screen after a few seconds. While
the “ ” information reminder is shown on
the display, it may be possible to display
the warning screen again. To recall the
message marked with “ ” on the display,
pull the “ /SET” switch on the steering
wheel toward you.
NOTE
Control switch
1)
(Up)
2)
/SET (enter)
3)
(Down)
By operating “ ” or “ ” of the control
switch, the screens and selection items
can be switched. When the “ /SET”
switch is pulled toward you, the item can
be selected and set.
If there are some useful messages, such
as vehicle information, warning informa-
tion, etc., they will interrupt the current
screen, and appear on the display accom-
panied by a beep. If such a screen is
displayed, take proper action according to
the message shown on the screen.
The warning screen will return to the
When the multi-function display (color
LCD) is set to the setting screen, the
combination meter display (color LCD)
cannot be controlled pressing on the
“ ”, “ ” and “ /SET” on the control
switch.
& Welcome screen (opening
animation) and Good-bye
(ending animation) screen
S03BN08
When the driver’s door is opened and
closed after unlocking the door, the wel-
come screen (opening animation) will
appear on the combination meter display
(color LCD) for approximately 20 seconds.
When the ignition switch is turned to the
“LOCK”/“OFF” position, the combination
meter display (color LCD) gradually turns
off by showing Good-bye screen (ending
animation).
