Warning and indicator
switch is pushed and held, we
recommend that you have your
vehicle inspected at a SUBARU
dealer as soon as possible.
& Auto Start Stop indica-
tor light (green)
S03AEA3
When a vehicle is stopped, the indicator
light illuminates when the operating con-
dition of idling stop are not meet. The light
will turn off when the vehicle starts driving.
Refer to “Non-operational conditions”
FP342.
& X-MODE indicator light (if
equipped)
S03AE68
X-MODE indicator (type B)
1) X-MODE indicator or D.SNOW/MUD
mode indicator
2) SNOW/DIRT mode indicator
This indicator appears while the X-MODE
is activated. It will disappear when the X-
MODE is deactivated. Refer to “To acti-
vate/deactivate the X-MODE” FP329.
& Hill descent control in-
dicator light (if
equipped)
S03AE69
S03AE66
This indicator light illuminates when the
engine has been temporarily stopped by
the Auto Start Stop system. It will turn off
when the engine is restarted.
X-MODE indicator (type A)
This indicator appears while the hill des-
cent control function is in standby. It will
flash while the hill descent control function
is operating. It will disappear when the hill
descent control function is not available.
Refer to “Hill descent control function”
FP331.
– CONTINUED –
The Auto Start Stop warning light will
illuminate in yellow if you open the engine
hood when the engine has been tempora-
rily stopped by the Auto Start Stop system.
In this case, to ensure safety, the engine
will not be automatically restarted, even if
you release the brake pedal. Use normal
operation to restart the engine.
! Auto Start Stop OFF indicator light
(yellow)
S03AE6502
This light will illuminate in yellow when the
Auto Start Stop OFF switch is pressed to
prevent the Auto Start Stop system from
operating. It will turn off when the Auto
Start Stop OFF switch is pressed once
more to enable operation of the Auto Start
Stop system.
& Auto Start Stop No
Activity Detected indi-
cator light
187
