140
Windows
“Initialization of power window (win-
dows with off delay function)” FP140. few seconds after the anti-entrapment
function operates.
! Anti-entrapment function (windows
with one-touch auto up and down
function)
S02AH0703
While closing the window automatically, if
the window senses a substantial enough
object trapped between the window and
the window frame, it automatically moves
down slightly and stops.
If a foreign object is caught while window is
opening automatically, the window will
stop. ! Off delay function (if equipped)
S02AH0705
The windows can be operated for approxi-
mately 40 seconds even after the ignition
switch is turned to the “ACC” or “OFF”
position. If a front door is opened within 40
seconds, the off delay function is can-
celed.
! Locking the passengers’ windows
S02AH0704
CAUTION
. Never attempt to test the power
window operation using body
parts fingers, hands or other
parts of your body.
. If an object is caught just before
the window fully closes, the sys-
tem may not operate properly.
NOTE
. If a window detects an impact similar
to that caused by trapping an object (for
example, when the vehicle encounters
a deep pothole), the anti-entrapment
function may operate.
. You cannot close the window for a
1)
2)
Lock
Unlock
When the lock switch is in the lock position,
the rear passenger’s window switches on
the driver side door and the passengers’
window switches cannot be operated.
& Initialization of power window
(windows with off delay func-
tion)
S02AH06
If the one-touch auto up and down function
or off delay function does not operate
properly, operate each window according
to the following procedure in order to
initialize the power window system.
1. Close the door.
2. Turn the ignition switch to the “ON”
position.
3. Open the window completely and then
press and hold down the power window
switch for approximately 1 second.
4. Close the window completely and then
pull and hold the power window switch for
approximately 1 second.
