Keyless access with push-button start system
! Registration for a PIN code
S02AP2102
Steps
Operation
Time from the previous step
1 Turn off the ignition switch. -
2 Close all doors (including rear gate). -
3 Press and hold the “ ” button on the access key fob, and press and hold the
rear lock button until a chirp sounds. -
4 Press and hold the “ ” button on the access key fob until a chirp sounds.
Within 30 seconds
The PIN code is inputted by using the rear lock button within 30 seconds after
the chirp sound of step 4.
For example, to register “32468” as the PIN code, perform the following
procedure.
5
(1) Press the button three times.
(2) After a chirp sounds once, press the button twice.
(3) After a chirp sounds once, press the button four times.
(4) After a chirp sounds once (ding), press the button six times.
(5) After a chirp sounds once (ding), press the button eight times.
Within 30 seconds
6 Perform step 5 again within approximately 30 seconds after the chirp starts
sounding intermittently. -
7 All doors will be unlocked and locked. Then the PIN code will be registered. -
NOTE
Press the “ ” button within 30 seconds of step 6 to end the preparation mode and move on to the registration stage. Unless the
“ ” button is pressed within 30 seconds after step 6, the PIN code registration will be canceled.
