SRS airbag (Supplemental Restraint System airbag)
97
! Example of the type of accident in
which the SRS side airbag will
most likely deploy.
! Example of the type of accident
S01AH0305
The SRS side airbag and SRS curtain
airbag are designed as follows:
. To deploy in the event of an accident
involving a moderate to severe side impact
collision
. To function on a one-time-only basis
S01AH030501
The SRS side airbag and SRS curtain
airbag are not designed to deploy in the
following cases:
. In most lesser side impacts
. In most frontal or most rear impacts
(because the SRS side airbag and SRS
curtain airbag deployment would not pro-
tect the occupant in those situations)
The SRS curtain airbags are also de-
signed to deploy when the vehicle is in an
extremely inclined state such as during a
rollover. They are not designed to deploy in
most lesser inclined state.
1)
A severe side impact near the front seat.
SRS side airbag and SRS curtain airbag
deployment depend on the level of force
experienced in the passenger compart-
ment during a side impact collision. That
level differs from one type of collision to
another, and it may have no bearing on the
visible damage done to the vehicle itself.
– CONTINUED –
