Instruments and controls / Multi function display
3-53
the length of operation in seconds and the number of activations will be displayed in the bar indicator, located on the lowermost part of the display.
If the Vehicle Dynamics Control system is activated, the activated vehicle wheels will be illuminated in yellow and the operating indicator“” will appear on the upper right part of the display. Also, the length of operation in seconds and the number of activations will be displayed in the bar indicator.
! EyeSight screen( models with the EyeSight system)
This screen displays the status of the EyeSight system.
!“ Boost pressure” and“ Accelerator opening ratio” screen( turbo models)
is stored if the ignition switch is turned to the“ ACC” or“ LOCK”/“ OFF” position. To reset the peak value, perform the following procedure.
Resetting procedure of boost pressure peak value
1. Push the button while the“ Boost pressure” and“ Accelerator opening ratio” screen is displayed. Then the following confirmation screen will appear.
1) |
Current vehicle speed |
2) |
Set vehicle speed |
3) |
Preceding vehicle |
4) |
Your vehicle |
1) |
Boost pressure( digital format) |
2) |
Boost pressure( analog format) |
3) |
Accelerator opening ratio( digital format) |
4) |
Accelerator opening ratio( analog format) |
5) |
Peak value of boost pressure( digital |
format) |
6) |
Peak value of boost pressure( analog |
format) |
This screen displays the boost pressure, the accelerator opening ratio and the peak value of the boost pressure in both the digital and analog formats.
Also, the peak value of the boost pressure
2. Select“ Yes” by operating the“” switch, and confirm the resetting by pushing the button.
If you select“ No”, the current peak value is still kept.
– CONTINUED –
