Instruments and controls/Multi function display
Fuel consumption results screen
1) The average fuel consumption for the
entire driving distance, from when the
ignition switch was turned to the “ON”
position to when it was turned to the
“LOCK”/“OFF” position.
2) The average fuel consumption for the
driving interval displayed on the trip
meter at the point when the ignition
switch was turned to the “LOCK”/“OFF”
position.
& Self-check screen
When the ignition switch is turned to the
“ON” position, the vehicle self-check will
be performed. The screens corresponding
to the following items will appear one after
another for several seconds each.
Type A combination meter
1) Engine oil: Checks the interval of engine
oil replacement.
2) Oil filter: Checks the interval of oil filter
replacement.
3) Tires: Checks the interval of tire rotation.
4) Inspection and maintenance: Checks the
interval of inspection and maintenance.
3-47
Type B combination meter
1) Windshield washer fluid: Checks the
level of windshield washer fluid.
2) Brake fluid: Checks the level of brake
fluid.
3) Engine oil: Checks the interval of engine
oil replacement.
4) Oil filter: Checks the interval of oil filter
replacement.
5) Tires: Checks the interval of tire rotation.
6) Inspection and maintenance: Checks the
interval of inspection and maintenance.
When the checks are performed, the color
of the icon corresponding to the checked
item will turn green.
If there is no warning message, the self-
check will complete without notification.
– CONTINUED –
