Instruments and controls/Warning and indicator lights
Warning and indicator lights : CHECK ENGINE warning light/Mal-
function indicator light
Several of the warning and indicator lights
illuminate when the ignition switch is
initially turned to the “ON” position. This
permits checking the operation of the
bulbs. : Coolant temperature low indicator
light/Coolant temperature high warn-
ing light
Apply the parking brake and turn the
ignition switch to the “ON” position. For
the system check, several of the following
lights illuminate and then turn off after
several seconds or after the engine has
started.
: Seatbelt warning light
(The seatbelt warning light turns off
only when the driver fastens the
seatbelt.)
: Front passenger’s seatbelt warning
light
(The seatbelt warning light turns off
only when the front seat passenger
fastens the seatbelt.)
: SRS airbag system warning light
ON /
/
: Front passenger’s frontal airbag
ON indicator light
: Front passenger’s frontal airbag
OFF indicator light
: Charge warning light
: Oil pressure warning light
: Engine low oil level warning light*
: Windshield washer fluid warning light*
: AT OIL TEMP warning light
(CVT models)
: Low tire pressure warning light
(U.S.-spec. models)
/ : ABS warning light
/ : Brake system warning light
: Low fuel warning light
: Hill start assist warning light/Hill start
assist OFF indicator light
: Door open warning light
: AWD warning light (CVT models)
: Power steering warning light
: Vehicle Dynamics Control warning
light/Vehicle Dynamics Control opera-
tion indicator light
3-13
: Vehicle Dynamics Control OFF indica-
tor light
: Cruise control indicator light
(if equipped)
: Cruise control set indicator light
(if equipped)
: Headlight indicator light (if equipped)
: Automatic headlight beam leveler
warning light (if equipped)
: Steering Responsive Headlight warn-
ing light/Steering Responsive Head-
light OFF indicator light (if equipped)*
: High beam assist indicator light (if
equipped)
: Access key warning light
(if equipped)
: X-mode indicator light (if equipped)
: Hill descent control indicator light (if
equipped)*
*: Applies to models with type A combina-
tion meter.
If any lights fail to illuminate, it indicates a
burned-out bulb or a malfunction of the
corresponding system.
Consult your authorized SUBARU dealer
for repair.
– CONTINUED –
