Keys and doors/Windows
CAUTION
After fully opening or fully closing a
window, do not continue to press
the switch in the same direction. It
may cause the power window to
malfunction.
NOTE
. Due to the structure of the vehicle
body, the rear seat window cannot be
fully opened.
. When the following operations are
performed, the power window breaker
will operate and it may not be possible
to open or close the window.
– After the driver’s window and, for
some models, the front passenger’s
window are fully closed or fully
opened, the switch is continuously
operated in the same direction for a
few seconds.
– After the windows for three or
more seats are fully closed or fully
opened, each switch is continu-
ously operated in the same direc-
tion simultaneously for a few sec-
onds.
. In this case, after the breaker re-
covers, be sure to initialize the power
windows. If they are not initialized, the
one-touch auto up/down function will
not operate. Refer to “Initialization of
power window” F2-38.
The power windows operate only when
the ignition switch is in the “ON” position.
2-33
All door windows can be controlled by the
power window switch cluster at the driver
side door.
! Operating the driver’s window
& Power window operation by
driver
! Driver’s side power window
switches
1)
2)
Automatically open/close
Open/close
To open:
Press the switch down lightly and hold it.
The window will open as long as the
switch is held.
1)
2)
3)
4)
5)
Lock switch
For driver’s window (with one-touch auto
up and down feature)
For front passenger’s window (with one-
touch auto up and down feature) (if
equipped)
For rear left window
For rear right window
NOTE
If you continue to hold the AUTO
switch in the down position after the
window has been fully opened, the
circuit breaker may activate for a short
time and the window may not operate.
Allow several seconds for the system
– CONTINUED –
