1-38
Seat, seatbelt and SRS airbags/Child restraint systems
on the rear seat window-side seating
positions. For each window-side seating
position, two lower anchorages are provided.
Each lower anchorage is located behind
the cover of the seatback bottom.
Some types of child restraint systems can
be installed on the rear seat of your
vehicle without use of the seatbelts. Such
child restraint systems are secured to the
designated anchorages provided on the
vehicle body. The lower and tether anchorages are sometimes referred to as the
LATCH system (Lower Anchors and
Tethers for CHildren).
Your vehicle is equipped with four lower
anchorages (bars) and three upper anchorages (tether anchorages) for accommodating such child restraint systems.
The tether anchorages (upper anchorages) are provided at the locations
shown in the above illustration. For details, refer to “Top tether anchorages” F140.
To install a child restraint system using
lower and tether anchorages, perform the
following procedure.
WARNING
The lower anchorages (bars) are provided
for installing a child restraint system only
Before installing a child restraint
system, be sure to confirm that the
