Instruments and controls/Multi function display
This screen displays the status of the
EyeSight system.
! “Boost pressure” and “Accelerator
opening ratio” screen (turbo models)
is stored if the ignition switch is turned to
the “ACC” or “LOCK”/“OFF” position. To
reset the peak value, perform the following
procedure.
3-53
! Triple meter screen
Resetting procedure of boost pressure
peak value
1. Push the
button while the “Boost
pressure” and “Accelerator opening ratio”
screen is displayed. Then the following
confirmation screen will appear.
Triple meter screen (display example)
1)
2)
3)
4)
5)
6)
Boost pressure (digital format)
Boost pressure (analog format)
Accelerator opening ratio (digital format)
Accelerator opening ratio (analog format)
Peak value of boost pressure (digital
format)
Peak value of boost pressure (analog
format)
This screen displays the boost pressure,
the accelerator opening ratio and the peak
value of the boost pressure in both the
digital and analog formats.
This screen displays up to three optional
pieces of information that can be selected
from the following items.
The items shown in the triple meter screen
can be changed. For details, refer to
“Triple meter setting” F3-72.
2. Select “Yes” by operating the “ ”
switch, and confirm the resetting by
pushing the
button.
If you select “No”, the current peak value
is still kept.
Also, the peak value of the boost pressure
– CONTINUED –
