Instruments and controls/Multi function display
switch is turned to the “ACC” or “ON”
position after it has been turned to
“LOCK”/“OFF” position.
! Information bar
Icy road surface warning screen
Information bar
Outside temperature indicator
Information reminder (models with type A
combination meter)
Top display
Clock
When the outside temperature becomes
378F (38C) or less, the icy road surface
warning screen interrupts to inform the
driver that the road surface may be frozen.
While the ignition switch is in the “ACC” or
“ON” position, the outside temperature
indicator, clock, etc. will be shown on the
information bar.
. The outside temperature indicator
shows the temperature around the
sensor. Therefore, the temperature indication may differ from the actual
outside air temperature.
. The icy road surface warning screen
should be treated only as a guide. Be
sure to check the condition of the road
surface before driving.
. Once the icy road surface warning
screen is displayed, it will not be
displayed again unless the ignition
1)
2)
3)
4)
5)
! Outside temperature indicator
This displays the outside temperature
between −408F (−408C) and 1228F
(508C).
3-49
NOTE
! Information reminder
The screen returns to the original screen
several seconds after the interruption
screen has been displayed. If the interruption screen can be displayed once
more even after the original screen has
appeared, an information reminder should
be displayed. For details about the interruption screen, refer to “Interruption
screen” F3-48.
! Top display
One of the following items can be displayed on the top display.
. Average fuel consumption corresponding to the driving distance of each trip
meter
. Current fuel consumption (This may
not be displayed when driving at a low
speed.)
. Driving range on remaining fuel
For details about the setting of the top
display, refer to “Top display setting” F368.
– CONTINUED –
