Instruments and controls/Meters and gauges
Meters and gauges
NOTE
Some of the meters and gauges on the
combination meter use liquid-crystal
displays. You will find their indications
hard to see if you wear polarized
glasses.
& Combination meter illumination
When the ignition switch is turned to the
“ON” position, various parts of the combination meter will illuminate in the following
sequence.
& Canceling the function for
meter/gauge needle movement upon turning on the
ignition switch
It is possible to activate or deactivate the
movement of the meter needles and
gauge needles that takes place when the
ignition switch is turned to the “ON”
position. To change the setting, perform
the following procedure.
3-9
The display can be switched as shown in
the following sequence by pressing the
trip knob.
! Type A combination meter
*: They cannot be displayed when the
ignition switch is in the “ON” position.
1. Turn the ignition switch to the “LOCK”/
“OFF” or “ACC” position.
To change the current setting, press the
trip knob for at least 2 seconds.
: Activated
: Deactivated
1. Warning lights, indicator lights, meter
needles, gauge needles and liquid crystal
display illuminate.
2. Meter and gauge indication
