Consumer information and Reporting safety defects/Tire information
. Passenger car tire
A tire intended for use on passenger cars, multipurpose passenger
vehicles, and trucks, that have a
gross vehicle weight rating (GVWR)
of 10,000 lbs (4,535 kg) or less.
. Ply
A layer of rubber-coated parallel
cords.
. Ply separation
A parting of rubber compound
between adjacent plies.
. Pneumatic tire
A mechanical device made of rubber, chemicals, fabric and steel or
other materials, that, when
mounted on an automotive wheel,
provides the traction and contains
the gas or fluid that sustains the
load.
. Production options weight
The combined weight of those
installed regular production options
weighing over 5.1 lbs (2.3 kg) in
excess of those standard items
which they replace, not previously
considered in curb weight or acces-
13-7
sory weight, including heavy duty
brakes, ride levelers, roof rack,
heavy duty battery, and special
trim.
. Rim type designation
. Radial ply tire
Nominal distance between rim
flanges.
A pneumatic tire in which the ply
cords that extend to the beads are
laid at substantially 90 degrees to
the centerline of the tread.
. Recommended inflation pressure
The cold inflation pressure recommended by a vehicle manufacturer.
. Reinforced tire
A tire designed to operate at higher
loads and at higher inflation pressures than the corresponding standard tire.
. Rim
A metal support for a tire or a tire
and tube assembly upon which the
tire beads are seated.
The industry of manufacturer’s designation for a rim by style or code.
. Rim width
. Section width
The linear distance between the
exteriors of the sidewalls of an
inflated tire, excluding elevations
due to labeling, decoration, or
protective bands.
. Sidewall
That portion of a tire between the
tread and bead.
. Sidewall separation
The parting of the rubber compound from the cord material in
the sidewall.
. Test rim
. Rim diameter
The rim on which a tire is fitted for
testing, and it may be any rim listed
as appropriate for use with that tire.
Nominal diameter of the bead seat.
. Tread
. Rim size designation
That portion of a tire F
