11-12
Maintenance and service/Engine oil
CAUTION
. Never over tighten the oil filter
because that can result in an oil
leak.
. Thoroughly wipe off any engine
oil that has spilled over the
exhaust pipe and/or under-cover.
If spilled oil is not promptly
wiped up, the oil could cause a
fire.
4. Drain out the engine oil by removing
the drain plug while the engine is still
warm. The used oil should be drained into
an appropriate container and disposed of
properly.
WARNING
Be careful not to burn yourself with
hot engine oil.
5. Wipe the seating surface of the drain
plug with a clean cloth and tighten it
securely with a new sealing washer after
the oil has completely drained out.
6. Remove the oil filter with an oil filter
wrench.
7. Before installing a new oil filter, apply a
thin coat of engine oil to the seal.
8. Clean the rubber seal seating area of
the engine and install the oil filter by hand
turning. Be careful not to twist or damage
the seal.
9. Tighten the oil filter according to the
standard number of rotations after the seal
makes contact with the seating surface.
10. Pour engine oil through the filler neck.
For the oil capacity (guideline), refer to
“Engine oil” F12-4.
The oil quantity indicated above is only
guideline.
The necessary quantity of oil depends on
the quantity of oil that has been drained.
The quantity of drained oil differs slightly
depending on the temperature of the oil
and the time the oil is left flowing out. After
refilling the engine with oil, therefore, you
must use the level gauge to confirm that
the level is correct.
11. Start the engine and make sure that no
oil leaks appear around the filter’s rubber
seal and drain plug.
12. Run the engine until it reaches the
normal operating temperature. Then stop
the engine and wait a few minutes to allow
