Starting and operating/Continuously variable transmission
7-27
& Selection of manual mode (if
equipped)
With the vehicle either moving or stationary, move the select lever from the “D”
position to the “M” position to select the
manual mode.
Models without EyeSight system
1) Upshift indicator
2) Downshift indicator
3) Gear position indicator
Models with EyeSight system
1) Upshift indicator
2) Downshift indicator
3) Gear position indicator
When the manual mode is selected, the
gear position indicator and upshift indicator and/or downshift indicator on the
combination meter illuminate.
The gear position indicator shows the
currently selected gear in the following
range.
. 1st-to-8th-gear range (when the Sport
Sharp (S#) mode is selected (if equipped))
. 1st-to-6th-gear range (in other situations)
The upshift and downshift indicators show
when a gear shift is possible. When the
upshift indicator “ ” illuminates, upshift– CONTINUED –
