4-14
Climate control/Air filtration system
and remove the hinge portion. When
doing this, be careful not to damage
the hinge.
1)
Stopper
(3) Push in the stoppers located on
both sides of the glove box and then
pull down the glove box as far as it will
go.
(4) Pull out the glove box horizontally
3. Replace the air filter element with a
new one.
2. Remove the air filter according to the
following procedure in order to prevent
dust on the air cleaner from falling to the
inside of its housing.
(1) Push in the four stoppers to
unlock, and then slowly pull out the
air filter 4 in (10 cm) from the housing.
(2) Completely pull out the air filter by
gently tilting the front side of the air
filter downward.
CAUTION
The arrow mark on the filter must
point UP.
