Instruments and controls/Mirrors
The exact location and color of the button
may vary by brand of garage door opener.
If it is difficult to locate the training button,
refer to your garage door opener’s instruction manual.
3-101
NOTE
Some garage door openers may require you to do the above press-holdrelease sequence a third time to complete the programming.
4. The garage door opener should now
recognize the HomeLink® Wireless Control
System and your garage door opener
should activate when the HomeLink ®
button is pressed.
! Programming for entrance gates
and garage door openers in
Canada
1. Unplug the motor of the entrance gate
or garage door opener from the outlet.
1)
Training button
2. Press the training button on the
garage door opener motor head unit
(which activates the “training light” on the
unit). Proceed to step 3 within 30 seconds.
3. Inside the vehicle, firmly press, hold for
2 seconds and release the HomeLink®
button that was programmed in the previous section. Press and release the
button a second time to complete the
programming procedure.
NOTE
If any of the HomeLink® buttons are
already programmed for other devices,
skip step 2 because it clears the
memory of all three buttons.
1)
2)
3)
HomeLink® button 1
HomeLink® button 2
HomeLink® button 3
2. Press and hold the two outer
HomeLink® buttons (button 1 and button
3) until the HomeLink® indicator light
begins to flash (after approximately 20
seconds). Then release both buttons.
3. Hold the end of the entrance gate’s/
garage door opener’s hand-held transmitter between 1 and 3 inches (25 and 76
mm) away from the HomeLink® button you
wish to program.
4. Press and hold the desired HomeLink®
button.
5. Press and release (“cycle”) the handheld transmitter button every 2 seconds
until step 6 is complete.
– CONTINUED –
