3-40
Instruments and controls/Multi function display
& Interruption screen
& Basic screens
! Information bar
These are the basic screens of the multi
function display.
Item
Page
Information bar
3-40
Fuel consumption screen
3-42
ECO gauge screen
Useful messages, such as reminder information, vehicle information, warning
information, etc. may interrupt the current
screen and appear on the display accompanied by a beep. Take proper action
according to the message.
The warning screen will return to the
original screen after a few seconds. If
the warning screen can be displayed
again, an information reminder “ ” will
appear on the upper left part of the
display. To recall the message marked
with “ ” on the display, pull the “ /SET”
switch on the steering wheel toward you.
3-42
Vehicle activation status
screen
Warning information (display example)
3-42
ECO history screen
3-43
EyeSight screen (models with
the EyeSight system)
3-44
Triple meter screen
3-44
“Boost pressure” and “Accelerator opening ratio” screen
(turbo models)
3-46
Guidance screen
3-45
Clock/calendar screen
3-45
By operating the “ ” or “ ” switch on the
steering wheel, you can switch the screen
that is always displayed. Also, when the
“ /SET” switch is pulled and held, the
selection screen can be displayed. For
details about the selection screen, refer to
“Selection screen” F3-47.
1)
2)
3)
4)
5)
Information bar
Outside temperature indicator
Information reminder
Top display
Clock
While the ignition switch is in the “ACC” or
“ON” position, the outside temperature
indicator, clock, etc. will be shown on the
information bar.
! Outside temperature indicator
This displays the outside temperature
between −408F (−408C) and 1228F
(508C).
