3-38
Instruments and controls/Multi function display
rear gate) is opened while the welcome
screen is displayed, the door ajar
warning will appear.
. The welcome screen can be set to
on or off. For details, refer to “Bypass
screen setting” F3-65.
. For a certain period of time after the
welcome screen has once appeared, it
may not appear again even when the
driver’s door is opened again. This
does not indicate a malfunction.
. “Goodbye” screen
. Fuel consumption results screen
& Ending screen
If the ignition switch is turned to the
“LOCK”/“OFF” position, one of the following screens will be displayed as the
ending screen before the screen turns off.
. If “Eco Summary” is set to “Off” in the
“Bypass screen setting”: The “Goodbye”
screen will be displayed.
. If “Eco Summary” is set to “On” in the
“Bypass screen setting”: The “Fuel consumption results screen” will be displayed.
For details about the bypass screen
setting, refer to “Bypass screen setting”
F3-65.
1)
2)
The average fuel consumption for the
entire driving distance, from when the
ignition switch was turned to the “ON”
position to when it was turned to the
“LOCK”/“OFF” position.
The average fuel consumption for the
driving interval displayed on the trip
meter at the point when the ignition
switch was turned to the “LOCK”/“OFF”
position.
& Self-check screen
When the ignition switch is turned to the
“ON” position, the vehicle self-check will
be performed. The screens corresponding
to the following items will appear one after
another for several seconds each.
