3-36
Instruments and controls/Multi function display
The clock can be set to 12-hour or 24-hour
clock displays. Perform the following
procedure to switch the display format.
1. Place the ignition switch in the
“LOCK”/“OFF” position.
2. Press and hold the “−” button that is
located near the clock display for approximately 5 seconds. The clock display will
then start to flash.
3. While the clock display is flashing,
press and hold the “+” button for approximately 2 seconds. The clock format will
then change.
4. The clock display will continue to flash
for approximately 3 seconds to inform you
that the clock display has been changed.
If you want to change the clock display
again, press and hold the “+” button for
approximately 2 seconds while the clock
display is flashing.
Multi function display (if
equipped)
NOTE
. If your vehicle is equipped with an
information display (monochrome), refer to “Information display (Mexicospec. models)” F3-31.
. Illustrations show the display for
U.S.-spec. models as an example. For
models other than U.S.-spec. models,
elements in the illustrations (such as
the display indication and measurement unit) may be different than the
ones for U.S.-spec. models.
. When the vehicle is in motion,
certain functions and selections may
not be available.
WARNING
Always pay adequate attention to
safe driving when operating the
multi function display while the
vehicle is in motion. When operation
of the multi function display is
disturbing your awareness and ability to concentrate on driving, stop
the vehicle in a safe place before
performing operations on the
screen. Also, do not concentrate
on the display while driving. Doing
so may cause you to look away from
the road and could result in an
accident.
The multi function display has the following functions.
Description
Page
Displays useful messages, such
as warning information, etc.
3-40
Displays basic screens (e.g. fuel
consumption screen, etc.)
3-40
Sets and adjusts maintenance
notification
3-67
Registers driving history
3-71
Sets and customizes car operation
3-72
Also, the multi function display can also be
used to set and initialize the multi function
display itself.
