Instruments and controls/Warning and indicator lights
Warning and indicator lights
: Coolant temperature high warning light
: Charge warning light
Several of the warning and indicator lights
illuminate when the ignition switch is
initially turned to the “ON” position. This
permits checking the operation of the
bulbs.
Apply the parking brake and turn the
ignition switch to the “ON” position. For
the system check, the following lights
illuminate and then turn off after several
seconds or after the engine has started.
: Seatbelt warning light
(The seatbelt warning light turns off
only when the driver fastens the
seatbelt.)
: Front passenger’s seatbelt warning
light
(The seatbelt warning light turns off
only when the front seat passenger
fastens the seatbelt.)
: SRS airbag system warning light
ON /
: Front passenger’s frontal airbag
ON indicator light
/
: Front passenger’s frontal airbag
OFF indicator light
3-11
: Cruise control indicator light
(if equipped)
: Oil pressure warning light
: Cruise control set indicator light
(if equipped)
: Engine low oil level warning light
: Headlight indicator light (if equipped)
: Windshield washer fluid warning light
: AT OIL TEMP warning light
(CVT models)
: Low tire pressure warning light
(U.S.-spec. models)
: Automatic headlight beam leveler
warning light (models with HID headlights)
: Access key warning light
(if equipped)
/
: ABS warning light
: X-mode indicator light (if equipped)
/
: Brake system warning light
: Hill descent control indicator light (if
equipped)
: Low fuel warning light
: Hill start assist warning light/Hill start
assist OFF indicator light
: Door open warning light
: AWD warning light (CVT models)
: Power steering warning light
: Vehicle Dynamics Control warning
light/Vehicle Dynamics Control operation indicator light
: Steering responsive fog lights OFF
indicator (models with the EyeSight
system)
If any lights fail to illuminate, it indicates a
burned-out bulb or a malfunction of the
corresponding system.
Consult your authorized SUBARU dealer
for repair.
: Vehicle Dynamics Control OFF indicator light
: CHECK ENGINE warning light/Malfunction indicator light
– CONTINUED –
