3-36
Instruments and controls/Multi function display
Multi function display (if
equipped)
The multi function display has the following functions.
Description
NOTE
. If your vehicle is equipped with an
information display (monochrome), refer to “Information display” F3-31.
. Illustrations show the display for
U.S.-spec. models as an example. For
models other than U.S.-spec. models,
elements in the illustrations (such as
the display indication and measurement unit) may be different than the
ones for U.S.-spec. models.
WARNING
Always pay adequate attention to
safe driving when operating the
multi function display while the
vehicle is in motion. When operation
of the multi-function display is disturbing your awareness and ability
to concentrate on driving, stop the
vehicle in a safe place before performing operations on the screen.
Also, do not concentrate on the
display while driving. Doing so may
cause you to look away from the
road and could result in an accident.
Page
Displays useful messages, such
as warning information, etc.
3-39
Displays basic screens (e.g. fuel
consumption screen, etc.)
3-40
Sets and adjusts maintenance
notification
3-66
Registers driving history
3-70
Sets and customizes car operation
3-71
Also, the multi function display can also be
used to set and initialize the multi function
display itself.
Multi function display
1) Outside temperature indicator
2) Information reminder
3) Top display (For the display setting, refer
to “Top display setting” F3-59.)
4) Clock
5) Driving information display (For the displayed contents, refer to “Basic screens”
