11-34
Maintenance and service/Replacement of wiper blades
& Rear window wiper blade
rubber
1. Pull out the end of the blade rubber
assembly to unlock it from the plastic
support.
Maintenance and service/Battery
2. Pull the blade rubber assembly out of
the plastic support.
1)
Metal spines
3. If the new blade rubber is not provided
with two metal spines, remove the metal
spines from the old blade rubber and
install them in the new blade rubber.
ends. If the rubber is not retained properly,
the wiper may scratch the rear window
glass.
5. Install the wiper blade assembly to the
wiper arm. Make sure that it locks in place.
6. Hold the wiper arm by hand and slowly
lower it in position.
4. Align the claws of the plastic support
with the grooves in the blade rubber
assembly, then slide the blade rubber
assembly into place.
Securely retain both ends of the rubber
with the stoppers on the plastic support
Battery
WARNING
. Before beginning work on or near
any battery, be sure to extinguish
all cigarettes, matches, and lighters. Never expose a battery to an
open flame or electric sparks.
Batteries give off a gas which is
highly flammable and explosive.
. For safety, in case an explosion
does occur, wear eye protection
or shield your eyes when working near any battery. Never lean
over a battery.
. Do not let battery fluid contact
eyes, skin, fabrics, or paint because battery fluid is a corrosive
acid. If battery fluid gets on your
skin or in your eyes, immediately
flush the area with water thoroughly. Seek medical help immediately if acid has entered the
eyes.
If battery fluid is accidentally
swallowed, immediately drink a
large amount of milk or water,
and seek medical attention immediately.
. To lessen the risk of sparks,
11-35
remove rings, metal watchbands,
and other metal jewelry. Never
allow metal tools to contact the
positive battery terminal and anything connected to it WHILE you
are at the same time in contact
with any other metallic portion of
the vehicle because a short circuit will result.
. Keep everyone including children
away from the battery.
. Charge the battery in a wellventilated area.
. Battery posts, terminals and related accessories contain lead
and lead compounds, chemicals
known to the State of California
to cause cancer and reproductive
harm. Batteries also contain
other chemicals known to the
State of California to cause cancer. Wash hands after handling.
– CONTINUED –
