Instruments and controls/Multi function display
following conditions.
– The period of time remaining
until the registered notification date
is 15 days or less.
– The total driving distance remaining until the registered notification
distance is approximately 311 miles
(500 km) or less.
. The maintenance notification screen
will be displayed until either of the
following conditions is satisfied.
– The period of time passed after
the registered notification date is 15
days or more.
– The total distance driven after the
registered notification distance is
approximately 311 miles (500 km) or
more.
& Interruption screen
3-39
& Basic screens
These are the basic screens of the multi
function display.
Item
Page
Information bar
3-40
Fuel consumption screen
3-41
ECO gauge screen
Useful messages, such as reminder information, vehicle information, warning
information, etc. may interrupt the current
screen and appear on the display accompanied by a beep. Take proper action
according to the message.
The warning screen will return to the
original screen after a few seconds. If
the warning screen can be displayed
again, an information reminder “ ” will
appear on the upper left part of the
display. To recall the message marked
with “ ” on the display, pull the “ /SET”
switch on the steering wheel toward you.
3-42
Vehicle activation status
screen
Warning information (display example)
3-41
ECO history screen
3-42
EyeSight screen (models with
the EyeSight system)
3-43
Triple meter screen
3-44
Guidance screen
3-44
Clock/calendar screen
3-45
Audio screen (if equipped)
3-45
By operating the “ ” or “ ” switch on the
steering wheel, you can switch the screen
that is always displayed. Also, when the
“ /SET” switch is pulled and held, the
selection screen can be displayed. For
details about the selection screen, refer to
“Selection screen” F3-47.
– CONTINUED –
