Instruments and controls/Multi function display
information display, the display will
automatically turn on when the battery
voltage is disconnected and then reconnected for battery replacement or
fuse replacement.
& Clock
To adjust the time shown by the clock,
press the “+” button or “−” button. If you
press the “+” button, the indicated time will
change in one-minute increments. If you
press the “−” button, the indicated time will
change in one-minute decrements. If you
keep the button pressed, the rate at which
the indicated time changes will speed up.
1. Place the ignition switch in the
“LOCK”/“OFF” position.
2. Press and hold the “−” button that is
located near the clock display for approximately 5 seconds. The clock display will
then start to flash.
3. While the clock display is flashing,
press and hold the “+” button for approximately 2 seconds. The clock format will
then change.
4. The clock display will continue to flash
for approximately 3 seconds to inform you
that the clock display has been changed.
If you want to change the clock display
again, press and hold the “+” button for
approximately 2 seconds while the clock
display is flashing.
3-35
Multi function display (if
equipped)
NOTE
If your vehicle is equipped with an
information display (monochrome), refer to “Information display” F3-30.
WARNING
Always pay adequate attention to
safe driving when operating the
multi function display while the
vehicle is in motion. When operation
of the multi-function display is disturbing your awareness and ability
to concentrate on driving, stop the
vehicle in a safe place before performing operations on the screen.
Also, do not concentrate on the
display while driving. Doing so may
cause you to look away from the
road and could result in an accident.
The clock can be set to 12-hour or 24-hour
clock displays. Perform the following
procedure to switch the display format.
– CONTINUED –
