3-36
Instruments and controls
mittently at intervals corresponding to the
vehicle speed (longer when the vehicle
speed is low; shorter when the vehicle
speed is high).
When you subsequently shift the transmission into reverse, the rear wiper will
automatically switch to continuous operation. When the transmission is shifted to a
position other than reverse, the rear wiper
will return to intermittent operation.
! Washer
To wash the rear window while the rear
wiper is operating, turn the knob upward to
the “ ” position. The washer fluid sprays
until you release the knob.
To wash the rear window when the rear
wiper is not in use, turn the knob downward to the “ ” position. The washer fluid
sprays, and 2 seconds later the rear wiper
operates. Releasing the knob stops the
washer fluid spray, and 3 seconds later
the rear wiper stops.
Mirrors
Always check that the inside and outside
mirrors are properly adjusted before you
start driving.
& Auto-dimming mirror/compass (if equipped)
& Inside mirror
1)
2)
3)
4)
5)
The inside mirror has a day and night
position. Pull the tab at the bottom of the
mirror toward you for the night position.
Push it away for the day position. The
night position reduces glare from headlights of vehicles behind you.
Auto dimming indicator
Left (mirror) button
Photosensor
Right (compass) button
Compass display
The auto-dimming mirror has an anti-glare
feature which automatically reduces glare
coming from headlights of vehicles behind
you. It also contains a built-in compass.
. By pressing and releasing the left
button, the automatic dimming function is
toggled on or off. When the automatic
dimming function is on, the auto dimming
indicator light (green) located on the left
button will illuminate.
. By pressing and releasing the right
