Instruments and controls
Type A:
/
/
: Activated
: Deactivated
NOTE
Your vehicle’s initial movement setting
of the meter/gauge needles has been
set for activation “
”/“ ” at the time
of shipment from the factory.
*: “
” or “ ”, and “
” or “ ” cannot
be displayed when the ignition switch is
in the “ON” position.
Type B:
& Meter needles/gauge illumination setting (models with
type A combination meter)
When the setting is activated or deactivated, the meter needles and gauge
illuminate and turn off as follows.
Activated:
When the driver’s door is opened while
the ignition switch is in the “LOCK”
position, the needles and gauge illuminate
and turn off after approximately 20 seconds.
When the ignition switch is turned from the
“ON” position to the “LOCK” position, the
illumination turns off gradually.
*: “ ” or “
” cannot be displayed when
the ignition switch is in the “ON” position.
3-7
Deactivated:
The needles and gauge do not illuminate
when the driver’s door is opened while the
ignition switch is in the “LOCK” position.
The illumination turns off immediately
when the ignition switch is turned from
the “ON” position to the “LOCK” position.
NOTE
. Even during the illumination after
the driver’s door is opened, if the
ignition switch is turned to the “ON”
position, the combination meter will
illuminate as usual.
. If the doors are locked by the remote
keyless entry system during the illumination after the driver’s door is opened,
the illumination will be turned off.
. Even while the illumination gradually turns off after the ignition switch is
turned to the “LOCK” position, if the
ignition switch is turned to the “ON”
position, the combination meter illuminates as usual.
To change the setting:
1. Turn the ignition switch to the “LOCK”
or “Acc” position.
3. To change the current setting, press
the trip knob for at least 2 seconds.
– CONTINUED –
