Interior equipment
& Cargo area light
1)
2)
3)
DOOR
OFF
ON
The cargo area light switch has the
following three positions.
DOOR: The light illuminates when the rear
gate is opened. The light remains illuminated for several seconds and turns off
after the rear gate is closed.
OFF: The light remains off.
ON: The light remains on continuously.
& Map light
1)
Map light switch (lens)
To turn on the map light, push the lens.
To turn it off, push the lens again.
When leaving the vehicle, make sure the
light is turned off to avoid battery discharge.
6-3
! Door interlock switch
1)
Door interlock switch
Although the map light switches (lenses)
are in the OFF position (manually off), the
map lights can be set to illuminate automatically in conjunction with the opening
of the doors by use of the door interlock
switch. The door interlock switch has the
following two positions.
OFF: The map lights do not illuminate
automatically in conjunction with the opening of the doors. But, the lights can be
turned on manually by pushing the map
light switches (lenses).
DOOR: The map lights illuminate automatically in the following cases.
. Any of the doors other than the rear
gate is opened. (The map lights do not
– CONTINUED –
