Audio
& MUTE button (models without Hands-free system)
Bluetooth® audio (type C and
D audio)
This function enables you to play back
audio sources from Bluetooth® audio
devices. You need to register the Bluetooth® audio device in the system before
using it.
& Media format
Press the “ ” button if you wish to
immediately cut the volume to zero.
The audio display will show “MUTE”.
If you press the button again, the original
sound volume will return and “MUTE”
turns off.
Bluetooth® audio devices cannot be
connected if they are not compatible with
the following Bluetooth® profiles.
. A2DP (Advanced Audio Distribution
Profile)
. AVRCP (Audio/Video Remote Control
Profile)
& Setting Bluetooth® audio
1. Select “BT-A SETUP” by pressing the
“MENU” button (type C audio)/Select “BT
Audio Setup” by pressing the “TUNE/
TRACK/CH” dial (type D audio).
2. Perform the following procedure by
operating the “TUNE/TRACK/CH” dial
while “BT-A” (type C audio)/“BT Audio”
(type D audio) is displayed.
5-41
NOTE
You cannot set a Bluetooth® audio
while driving.
! Registering (pairing) device
1. Select the “PAIR AUDIO” (type C
audio)/“Pair Audio Player” (type D audio)
menu. If a device is already registered,
“MEMORY FULL” is displayed and the
mode changes to the Bluetooth® audio
setting mode.
2. After the passkey is shown on the
display, input the passkey into the cell
phone. If you input the correct passkey,
“PAIRED” is displayed and the registering
procedure is finished. If you input an
incorrect passkey, “FAILED” is displayed,
the registering procedure was not successful and the mode changes to the
Bluetooth® audio setting mode.
NOTE
After the ignition switch is turned to the
“LOCK” position, the registered device
is not automatically connected to the
system even if the ignition switch is
turned to the “Acc” or “ON” position.
! Selecting device
1. Select the “SELECT AUDIO” (type C
audio)/“Select Audio Player” (type D
– CONTINUED –
