Climate control
! Temperature control dial
! Airflow control dial
4-15
(Heat-def): Windshield defroster outlets, foot outlets and both side outlets of
the instrument panel
: Windshield defroster outlets and both
side outlets of the instrument panel
For details, refer to “Airflow selection” F42.
NOTE
When the dial is placed in the “ ” or
“ ” position, the air inlet selection is
automatically set to “outside air”
mode.
This dial is used to set the desired interior
temperature. With the dial set to your
desired temperature, the system automatically adjusts the temperature of air
supplied from the outlets such that the
desired temperature is achieved and
maintained.
If the dial is turned fully counterclockwise,
the system gives maximum cooling performance. If the dial is turned fully clockwise, the system gives maximum heating
performance.
The dial has six positions that activate the
following outlets.
AUTO: The airflow control is adjusted
automatically in accordance with the air
temperature inside and outside the passenger compartment, the intensity of sunlight, and other factors. SUBARU recommends using the AUTO position.
(Ventilation): Instrument panel outlets
(Bi-level): Instrument panel outlets and
foot outlets
(Heat): Foot outlets, both side outlets of
the instrument panel and some through
windshield defroster outlets (A small
amount of air flows to the windshield and
both side windows to prevent fogging.)
! Air inlet selection button
ON position (Recirculation): Interior air
is recirculated inside the vehicle. Push the
air inlet selection button to the ON position
– CONTINUED –
