4-12
Climate control
! A/C – Air conditioner button
! Airflow mode selection button
lets, foot outlets and both side outlets of
the instrument panel
NOTE
When the “ ” mode is selected, the air
conditioner compressor automatically
operates to more quickly defog the
windshield. At the same time, the air
inlet selection is automatically set to
” mode (outside air mode).
the “
If the windshield starts to fog when the
climate control system is operated in the
AUTO mode, press the air conditioner
button “A/C” to defog and dehumidify.
When this button is pressed, the air
conditioner compressor turns on and the
indicator light “A/C” on the display illuminates. To turn off the air conditioner
compressor, press the “A/C” button again.
NOTE
The air conditioner compressor does
not operate when the outside air temperature is below 328F (08C).
Select the desired airflow mode by pressing the airflow mode selection button. The
selected airflow mode is indicated on the
display.
There are four airflow modes that activate
the following air outlets.
(Ventilation): Instrument panel outlets
(Bi-level): Instrument panel outlets and
the foot outlets
(Heat): Foot outlets, both side outlets of
the instrument panel and some through
windshield defroster outlets (A small
amount of air flows to the windshield and
both side windows to prevent fogging.)
(Heat-def): Windshield defroster out-
