Climate control
& Fan speed control dial
NOTE
With the fan speed control dial in the
AUTO position and the air flow control
dial in the “ ”, “ ”, or “ ” position,
the fan does not operate during engine
warm-up until the engine coolant temperature exceeds approximately 1228F
(508C).
4-9
the system gives maximum cooling performance. If the dial is turned fully clockwise, the system gives maximum heating
performance.
& Air flow control dial
& Temperature control dial
The fan operates only with the ignition
switch in the ON position. The fan speed
control dial is used to select the AUTO
(automatic control) mode or to select the
desired fan speed. The dial’s positions
and their functions are as follows.
OFF: The fan does not operate.
AUTO: The fan speed is adjusted automatically in accordance with the air
temperature inside and outside the passenger compartment, the intensity of sunlight, and other factors. SUBARU recommends using the AUTO position.
Other positions: The fan speed can be
adjusted in 7 steps.
This dial is used to set the desired interior
temperature. With the dial set to your
desired temperature, the system automatically adjusts the temperature of air
supplied from the outlets such that the
desired temperature is achieved and
maintained.
If the dial is turned fully counterclockwise,
This dial has the following six positions.
The outlets from which air is supplied in
each position are as follows.
AUTO: The air flow control is adjusted
automatically in accordance with the air
temperature inside and outside the passenger compartment, the intensity of sunlight, and other factors. SUBARU recommends using the AUTO position.
: Instrument panel outlets
: Instrument panel outlets and foot
outlets
– CONTINUED –
