Rear Seats 39 |
||||||||
|
they are designed to reduce the risk of serious neck injury in the event that the vehicle is struck from the rear. Therefore, when the head restraints are removed, all head restraints must be reinstalled properly to protect vehicle occupants.
. All occupants, including the driver, should not operate a vehicle or sit in a vehicle’ s seat until the head restraints are placed in their proper positions in order to minimize the risk of neck injury in the event of a crash.
. The front seat head restraints are designed to be installed into the front seats only. The rear seat head restraints are designed to be installed into the rear seats only. Do not attempt to install the front seat head restraints into the rear seats, or the rear seat head restraints into the front seats.
|
! Rear windows side seating position s01ac0301 |
1 Head restraint 2 Release button
To remove:
While pressing the release button, pull out the head restraint.
To install:
Install the head restraint into the holes that are located on the top of the seatback until the head restraint locks. Press and hold the release button to lower the head restraint.
|
After installing the head restraint, make sure it is securely locked.
NOTE
When the head restraint cannot be pulled out or installed due to insufficient
|
clearance between the head restraint and the roof, tilt the seat and then perform the installation and removal tasks.
! Rear center seating position
|
1 Incorrect( retracted position) 2 Correct( extended position)
CAUTION
s01ac0302
The head restraint is not intended to be used in the retracted position. Before sitting on the seat, raise the head restraint to the extended position.
|
1
Seat, Seatbelt and SRS Airbags
|
||
– CONTINUED – |
