520
Tire Information
Type B
( 1) DOT symbol *( 2) Plant Code( 3) Manufacturer’ s Code( 4) Date of Manufacture
The first two figures identify the week, starting with“ 01” to represent the first full week of the calendar year; the second two figures represent the year. For example, 0101 means the 1st week of 2001.
*: The DOT symbol certifies that the tire conforms to applicable Federal Motor Vehicle Safety Standards.
! Other markings s13ab0103
The following makings are also placed on the sidewall.
! Maximum permissible inflation pressure s13ab010301
The maximum cold inflation pressure to which this tire may be inflated. For example,“ 350 kPa
( 51 PSI) MAX. PRESS”! Maximum load rating s13ab010302
The load rating at the maximum permissible weight load for this tire. For example,“ MAX. LOAD 615 kg( 1,356 LBS) @ 350 kPa( 51 PSI) MAX. PRESS.”
WARNING
Maximum load rating applies only to the tire, not to the vehicle. Putting a load rated tire on any vehicle does not mean the vehicle can be loaded up to the tire’ s rated load.
! Construction type s13ab010303
Applicable construction of this tire.
For example,“ TUBELESS STEEL BELTED RADIAL”
! Construction s13ab010304
The generic name of each cord material used in the plies( both sidewall and tread area) of this tire.
For example,“ PLIES: TREAD 2 STEEL + 2 POLYESTER + 1 NYLON SIDEWALL 2 POLYE- STER”
! Uniform Tire Quality Grading( UTQG) s13ab010305
For details, refer to“ Uniform Tire Quality Grading Standards” FP531.
& Recommended Tire Inflation Pressure s13ab02
! Recommended cold tire inflation pressure s13ab0201
For the recommended cold tire inflation pressure for your vehicle’ s tires, refer to“ Tires” FP510.
