Replacement of Wiper Blades 487 |
|
scratched.
If you cannot eliminate the streaking even after following this method, replace the wiper blades using the following procedures.
|
CAUTION
Hold the wiper arm when replacing the wiper blade. Holding the wiper blade, may result in blade deformation.
|
|||||
|
& Windshield Wiper Blade Assembly s11az01
NOTE
Do not lower the wiper arm while the wiper blade assembly is removed.
1. Raise the wiper arm off the windshield. First raise the driver’ s side wiper arm and then raise the front passenger’ s side wiper arm.
|
1 Lock knob
2. Hold the wiper blade connection by hand, push the lock knob to release the lock, and then pull out the wiper blade assembly.
NOTE
Do not use a hard object to push the lock knob. The lock knob may be scratched.
|
3. When installing the wiper blade assembly, align it with the wiper arm connection part and then slide it in the opposite direction of removal to install. After installing the wiper blade assembly, check that the connection part is locked completely.
4. Hold the wiper arm by hand and slowly lower it in position.
|
Maintenance and Service
11
|
|||
– CONTINUED – |
