BSD / RCTA 365 |
||||||
reversing the vehicle. |
Example 2 1 The detection range of the radar sensors C Vehicle that may be detected
NOTE
The system may detect that a vehicle( C) is passing in front of your vehicle. Always be sure to check the surroundings with your eyes when reversing the vehicle.
& System Operation
s07bm02
! Operating conditions s07bm0201
The BSD / RCTA will operate when all of the following conditions are met.
|
. The ignition switch is in the“ ON” position.
. The BSD / RCTA warning indicator and BSD / RCTA OFF indicator are turned off.
. The vehicle is driven at speeds above 7 mph( 12 km / h)( except when reversing).
. The select lever is in the“ R” position( RCTA only).
The BSD / RCTA will not operate in the following situations.
. The BSD / RCTA OFF indicator appears.
. The vehicle speed is below 6 mph( 10 km / h) even when the BSD / RCTA OFF indicator does not appear( except when reversing).
NOTE
. In the following cases, the BSD / RCTA will stop operating and the BSD / RCTA warning indicator will appear. – When a malfunction occurs in the system, including the BSD / RCTA approach indicator light
. If the BSD / RCTA warning indicator appears, exercise proper caution. For details, refer to“ BSD / RCTA Warning Indicator” FP369.
|
. In the following cases, the BSD / RCTA will temporarily stop operating( or may stop operating) and the BSD / RCTA OFF indicator will appear. – When the radar sensor becomes significantly misaligned( If the orientation of the radar sensor is shifted for any reason, readjustment is required. Have the sensor adjusted at a SUBARU dealer.)
– When a large amount of snow or ice sticks to the rear bumper surface around the radar sensors
– When the vehicle is driven on a snow-covered road or in an environment in which there are no objects around( such as in a desert) for a prolonged period of time
– When the temperature around the radar sensors increases excessively due to long driving on uphill grades in the summer, etc.
– When the temperature around the radar sensors becomes extremely low
– When the vehicle battery voltage lowers
– When the vehicle voltage exceeds the battery voltage rating
|
7
Starting and Operating
|
||
– CONTINUED – |
