302
Cargo Tie-Down Hooks
|
& To Install the Cover Housing s06ak05
The right end of the cargo area cover is a sliding structure.
|
|
|
|
6-15. Cargo Tie-Down Hooks
s06am
|
6-16. Under-Floor Storage Compartment |
s06an |
1. Insert the right end of the cover into the recessed portion with the arrow mark facing upward.
2. Hold the cover housing securely and insert the left end of the cover into the recessed portion.
The cargo area is equipped with four tiedown hooks so that cargo can be secured with a cargo net or ropes.
When using the front tie-down hooks, turn them down out of the storing recesses.
CAUTION
The cargo tie-down hooks are designed only for securing light cargo. Never try to secure cargo that exceeds the capacity of the hooks. The maximum load capacity is 22 lbs( 10 kg) per hook.
The subfloor storage compartment is located under the floor of the cargo area and can be used to store small items. To open the lid, pull the strap up.
CAUTION
. Always keep the lid of the subfloor storage compartment closed while driving to reduce the risk of injury in the event of sudden stop or an accident.
. Do not store spray cans, containers with flammable or corrosive liquids or any other dangerous items in the subfloor storage
