Wireless Charger 293 |
|||
|
NOTE
The power status of the wireless charger is stored even when the ignition switch is turned to the“ OFF” position.
! How to use the quick charge s06bh0101
The following types of mobile devices support quick charging as opposed to normal charging( 5 W).
. Mobile devices compliant with WPC * Ver. 1.2.4 and compatible with fast chargers can be charged up to 10 W.
. iPhone 8( or later) with an iOS version compliant with WPC * Ver. 1.2.4 and compatible with 7.5 W charging.
* WPC: Wireless Power Consortium
1. Press the power switch three times to change to the quick-charging mode while your mobile device is charging in normal mode. The indicator light will change from orange to alternating green and orange when the wireless charger switches to the quick-charging mode.
2. When charging is complete, the quickcharging mode ends. To restart quickcharging, switch to the quick-charging mode again.
|
! Indicator light patterns
Indicator light
Off
Green( illuminated)
Orange( illuminated)
Green and orange illuminate alternately
s06bh0102
Interpretation The wireless charger is turned off
Standby( ready for charging)* 1
Charging is complete * 2 A mobile device is in the charging area( a mobile device is being detected)
Charging
Quick charging is in progress
* 1: No power is output for charging when the wireless charger is in standby mode. Even if metal objects are placed on the charging tray in this state, they will not overheat.
* 2: For some mobile devices, the indicator light remains orange even after charging is complete.
|
! List of warnings
Indicator light
Flashes orange once per second
Repeatedly flashes orange three times
Possible causes
A communication error occurred between the wireless charger and the access key fob.
Metallic foreign object detected. A foreign object is detected between the mobile device and the charging area. The mobile device is out of alignment: The overheat prevention function of the charging coils was triggered because the mobile device’ s charging coils were out of alignment with the charging area.
Solution
s06bh0103
If the engine is running, stop the engine and restart it. If the ignition switch is in“ ACC”, start the engine once.
Remove any foreign objects between the mobile device and the charging area. Remove the mobile device from the charging area, check that the activation indicator light is illuminating in green again, and place the device in the center of the charging area. If there is a case or cover on your mobile device, be sure to remove it.
– CONTINUED –
|
6
Interior Equipment
|
