Headlight Beam Leveler 239 |
|||||||
|
light will illuminate and turn off after several seconds.
. SRH only activates when the vehicle is traveling forward at the speed of approximately 5 mph( 8 km / h) or more.
|
3-13. Headlight Beam Leveler
s03at
The LED headlights produce more light than conventional halogen headlights.
When the vehicle is carrying a heavy load and the headlight beams are angled upwards, the driver of an oncoming vehicle may experience glare.
To prevent this, the automatic headlight beam leveler adjusts the headlights to the optimum height automatically depending on the load the vehicle is carrying.
|
CAUTION
In certain circumstances, the headlights may become misaligned, and the headlight beam leveler will not reset them to the proper angle. This may occur after transporting your vehicle on a flat-bed truck, or if the vehicle is parked and restarted on different angles. In such cases, have the headlight alignment checked by a SUBARU dealer.
|
3-14. Front Fog Light Switch( If Equipped) |
1 Headlight switch 2 Fog light switch
s03ba
To turn on the front fog lights:
Turn the fog light switch to the“” position while the headlights are in either of the following conditions.
. The headlight switch is in the“” position with the low beam mode selected.
. The headlight switch is in the“ AUTO” position and the low beam headlights turn on automatically.
|
3
Instruments and Controls
|
||
– CONTINUED – |
