164
Warning and Indicator Lights
the“ ON” position again.
. The brake system warning light may illuminate immediately after the engine is started. However, it is not malfunctioning if the warning light turns off after the electronic parking brake is released.
. The brake system warning light may illuminate after the electronic parking brake is frequently applied and released. However, the electronic parking brake system is not malfunctioning if the light turns off after a short period of time.
. When the engine is started while the electronic parking brake is applied / released, the system may judge an abnormal situation and the warning light may illuminate. If the warning light illuminates, turn the ignition switch once to the“ LOCK”/“ OFF” position and then restart the engine. Then, apply / release the electronic parking brake. If the warning light turns off, the system will be restored.
This light has the following functions.! Brake fluid level warning s03ae1002
This light illuminates when the brake fluid level has dropped to near the“ MIN” level of the brake fluid reservoir with the ignition switch in the“ ON” position and with the parking brake fully released.
If the brake system warning light should illuminate while driving( with the parking brake fully released and with the ignition switch positioned in“ ON”), it could be an indication of leaking of brake fluid or worn brake pads. If this occurs, immediately stop the vehicle at the nearest safe place and check the brake fluid level. If the fluid level is below the“ MIN” mark in the reservoir, do not drive the vehicle. Have the vehicle towed to the nearest SUBARU dealer for repair.
! Electronic Brake Force Distribution( EBD) system warning s03ae1003
If the warning light remains on even though the parking brake is released, the brake fluid level may be low or there could be a problem with the EBD system. Park the vehicle in a safe place immediately and contact a SUBARU dealer.
! Electronic brake booster warning s03ae1009
The brake system warning light illuminates when the electronic brake booster is malfunctioning. In addition, the warning messages“ Brake System” and“ Check Owner’ s Manual” are displayed alternately on the combination meter display( color LCD). If the warning light illuminates, promptly park in a safe location as soon as possible and contact your SUBARU dealer.
! Electronic parking brake system warning s03ae1004
The brake system warning light illuminates when the electronic parking brake system is malfunctioning. If the warning light illuminates, promptly park in a safe location as soon as possible and contact your SUBARU dealer.
The brake system warning light remains illuminated when the parking brake cannot be released even if the parking brake switch is pushed. For details, refer to“ Electronic Parking Brake” FP346.
! Frequent operation warning s03ae100403
The brake system warning light illuminates and a chirp sound will be heard if the parking brake switch is operated too frequently. In this case, the operation of the parking brake switch is restricted to protect the electronic parking brake system.
& Electronic Parking Brake Indicator Light
s03ae85
! Parking brake indicator s03ae8501
The light illuminates with the parking brake applied while the ignition switch is in the“ ACC” or“ ON” position. It turns off when
